Frame and racks:
Frame: Universal-fit / Chrome-moly steel frame / integrated cable routing / footboard-ready
Size: One size (for persons from 150 cm to 210 cm / 4'11" to 6'11")
Fork: VELLO SUB / Material: Aluminium 20” / Postmount disc mount / Thru-axle / for tires up to 60-406 (20x 2.35") / Integrated cable routing
Rear rack (integrated): 68.5 cm x 13.5 cm (27" x 5.3"), Maximum load: 100 kg (220 lbs), Aluminium / with integrated MIK-HD system
MIK-HD integration: Compatible with all MIK and MIK-HD accessories, tool-free attachment of up to 2 child seats from renowned manufacturers
Front rack: up to 22 kg (48.5 lbs)
Front carrier block adapter: Allows tool-free attachment of various front racks or bags
Drive and braking system:
Motor: BOSCH® Cargo Line (Gen 5) / up to 120Nm / Smart System (GPS-tracking-ready)
Battery: BOSCH® Power Pack Frame (400Wh – 800 Wh per battery slot, up to 2 batteries can be installed)
Range: up to 350 km (217 miles) with 1,600Wh (2x800Wh) in Eco+ mode
Charger: Bosch® / 4A (230 V)
Charging time: 4.5 hours (full charge 400Wh)
Front hub: VELLO / 36-hole / 12x100 / Thru-axle
Rear hub: Enviolo® Heavy Duty / 36-hole / 148 mm
Shifter: Enviolo® Twist Pro with display
Belt: Gates® Carbon Drive / CDX / 168T
Front sprocket: Gates® Carbon Drive / CDX / 63T
Rear sprocket: Gates® Carbon Drive / CDX / 22T
Development: 2.22 m - 8.42 m (7'3" - 27'7")
Braking system front/rear: MAGURA® / Louise Elite Leisure / four-piston disc brake system
Front brake disc: MAGURA® MDR-C / 180mm (7") / 6-bolt mount
Rear brake disc: MAGURA® MDR-C / 160mm (6.3") / 6-bolt mount
Components:
Handlebar: VELLO Flat-Bar 640 mm (25.2")
Grips: Selle Royal® NIVO plus; ergonomic grips
Saddle: Selle Royal® Rio; gel saddle with carrying handle
Saddle post: VELLO / Material: Aluminium / Ø31.6 / 400 mm (15.7")
Telescopic stem: by.schulz® Speedlifter Twist / T15 / tool-free height adjustment and 90-degree rotation
Stem: Satori® EZ-X with SP-Connect® mount tool-free adjustable
Tires: Schwalbe® Pick Up 20x2.35" (ETRTO 60-406) / with reflective ring
Pedals: Ergotec® EP-F platform folding pedal
Front light: Supernova® Mini 2-LDM (StVZO-approval)
Rear light: Supernova® TL3 Pro with brake light function
Bell: Widek® E-Bike Bell
Double-leg kickstand: URSUS® Sumo
Fenders front/rear: VELLO
Dimensions and weights:
Vehicle weight: approx. 28.9 kg (63.7 lbs) (without pedals, +/- 5%) with 400Wh battery (gears)
Permissible total weight (vehicle+rider+load): 210 kg (463 lbs)
Dimensions (folded): H: 85 cm x L: 180 cm x W: 29 cm (33.5" x 70.8" x 11.4")
Warranty: Lifetime warranty on the frame. Activate your warranty as the first owner simply by registering online within 6 weeks of purchase. 2 years on motor and battery.
